Overview of the 34934A 1
Keysight 34934A User’s Guide 27
These examples introduce one of the SCPI paired commands;
ROUTe:CLOSe:PAIR. With pair commands, you specify only the H channel
numbers; but both the H and L channels of a pair are operated (e.g. opened or
closed).
C1H – C32H
M1H
. . .
M1L
C1H – C32H
. . .
1303
1533
1563
M2H
M2L
C1L – C32L
. . .
C1L – C32L
. . .
1302
INST
-
+
DUT
+
-
-
+
DUT
+
-
INST
ROUT: CLOS : PAIR (@ 1302 , 1303 )
Paired channels are: 1366 1367
ROUT: CLOS: PAIR (@ 1533 , 1563 )
Paired channels are: 1597 1627
1366
1367
1597
1627
R3H
R1H
R2H R4H
R3H
R1H
R2H R4H
R3L
R1L
R2L R4L
R3L
R1L
R2L R4L
Closes:
row R2H @ columns C2H and C3H
row R2L @ columns C2L and C3L
row R3H @ columns C1H and C31H
row R3L @ columns C1L and C31L
Closes:
See “Channel Numbering” on page 168 for the numbering scheme.
