List of Test Equipment
Below is a list of test equipment and accessories required to perform the
performance test verification procedures.
Table 1 List of test equipment
Equipment Critical Specifications Recommended Model/
Part Number
Digital Multimeter 0.1 mV resolution, 0.005% accuracy Keysight 34401A
Power Splitter Outputs differ by 0.15 dB Keysight 11667B
Oscilloscope Calibrator DC offset voltage of -5.5 V to 70.5 V, 0.1 V resolution
25 MHz—500 MHz sine wave, 5 ppm
Fluke 5820A
Signal Generator 25 MHz, 100 MHz, 350 MHz, 500 MHz, and 1 GHz
sine waves
Keysight N5181A
Power Meter 1 GHz
±3% accuracy Keysight N1914A
Power Sensor 1 GHz ±3% accuracy Keysight E9304A or
N8482A
BNC banana cable BNC (m) to dual banana Pomona 2BC-BNC-36 or
Keysight 11001-66001
BNC cable (qty 3) BNC - BNC, 48” length Keysight 10503A
†
Cable Type N (m) 609.6 mm (24 in.) Keysight 11500B
Adapter BNC(f) to banana(m) Keysight 1251-2277
†
Adapter BNC Tee (m) (f) (f) Keysight 1250-0781
†
or
Pomona 3285
Adapter Type N (m) to BNC (m) Keysight 1250-0082 or
Pomona 3288 with
Pomona 3533
Blocking capacitor and shorting cap Note: if a BNC blocking capacitor is not available use an
SMA blocking capacitor.
Keysight 11742A +
Pomona 4288 +
Pomona 5088
Adapter (qty 3) N(m) to BNC(f) Keysight 1250-0780
50 Ohm Feedthrough Termination 50
Ω BNC (f) to BNC (m) Keysight 0960-0301
Most parts and equipment are available at www.keysight.com. See respective manufacturer’s websites for their equipment.
†
These parts available at www.parts.keysight.com at the time this manual was published.
