Keysight E3631A - General Calibration;Adjustment Procedure

Calibration Procedures 3
Keysight E3631A Service Guide 79
General calibration/adjustment procedure
The calibration procedures from the front panel are described in this section. For
output voltage calibration, disconnect all loads from the power supply and
connect a DVM across the output terminals to be calibrated. For output current
calibration, disconnect all loads from the power supply, connect an appropriate
current monitoring resistor across the output terminals to be calibrated, and
connect a DVM across the terminals of the monitoring resistor.
The following table shows calibration parameters and points which should be
used to calibrate the output voltage and current for each of the three outputs.
Table 3-3 Parameters for Calibration
Output
Calibration
Parameter
Voltage/Current
Calibration Point
mnemonic
+6V output
CAL SETUP 1 Voltage
V LO
V HI
CAL SETUP 2 Current
I LO
I HI
+25V output
CAL SETUP 3
Voltage
V LO
V HI
CAL SETUP 4
Current
I LO
I HI
-25V output
CAL SETUP 5
Voltage
V LO
V HI
CAL SETUP 6
Current
I LO
I HI
NOTE
You can terminate any CAL SETUP without changing its calibration constants by
turning off power.
