1 Specifications
26 Keysight E3631A Service Guide
Performance Specifications
Table 1-1 Performance Specifications
Item Specifications
Output ratings (@ 0°C - 40°C)
+6V Output 0 to +6 V ; 0 to 5 A
+25V Output 0 to +25 V ; 0 to 1 A
–25V Output 0 to –25 V ; 0 to 1 A
Programming accuracy
[1]
12 months (@ 25°C ± 5°C), ±(% of output + offset)
+6V output +25V output –25V output
Voltage 0.1% + 5 mV 0.05% + 20 mV 0.05% + 20 mV
Current 0.2% + 10 mA 0.15% + 4 mA 0.15% + 4 mA
Readback accuracy
[1]
12 months (over GPIB and RS-232 or front panel with respect to actual output @ 25°C ± 5°C), ±(% of
output + offset)
+6V output +25V output –25V output
Voltage 0.1% + 5 mV 0.05% + 10 mV 0.05% + 10 mV
Current 0.2% + 10 mA 0.15% + 4 mA 0.15% + 4 mA
Ripple and noise (with outputs ungrounded, or with either output terminal grounded, 20 Hz to 20 MHz)
+6V output +25V output –25V output
Voltage
<0.35 mV rms <0.35 mV rms <0.35 mV rms
<2 mV p-p <2 mV p-p <2 mV p-p
Current <2 mA rms <500 mA rms <500 mA rms
Common mode current <1.5 mA rms
Load regulation, ±(% of output + offset)
Change in output voltage or current for any load change within ratings
Voltage <0.01% + 2 mV
Current <0.01% + 250 mA
Line regulation, ±(% of output + offset)
Change in output voltage and current for any line change within ratings
