Keysight E3631A Service Manual

3 Calibration Procedures
86 Keysight E3631A Service Guide
15
"CAL SETUP 5" now appears on the display (press "Calibrate"
key).
-25 supply
16
"V LO -0.5000 V" appears on the display (change the display to
match the DVM reading; then press "Calibrate" key).
V -25 supply
17
"V HI -24.750 V" appears on the display (change the display to
match the DVM reading; then press "Calibrate" key).
V -25 supply
18
"CAL SETUP 6" now appears on the display (press "Calibrate"
key).
-25 supply
19
"I LO 0.100 A" appears on the display (change the display to
match the computed current through 0.1? resistor; then press
"Calibrate" key).
A -25 supply
20
"I HI +0.950 A" appears on the display (change the display to
match the computed current through 0.1? resistor; then press
"Calibrate" key).
A -25 supply
