I MI 3.5000 A
If the entered number is within an acceptable range, an ENTERED message
appears for one second. If the entered number is not correct, a MIN VALUE or
MAX VALUE message appears for one second and the display shows the low
current calibration point again. The display now shows the middle current
calibration point.
16 Read the DVM and change the middle current value on the display to match
the computed current (DVM reading divided by shunt resistance).
For example, if the computed value is 3.499 A, adjust the current to 3.499 A
using the knob and arrow keys.
I MI 3.4990 A
17 Pressing the Calibrate key saves the change and selects the high current
calibration point.
I HI 6.9000 A
If the entered number is within an acceptable range, an ENTERED message
appears for one second. If the entered number is not correct, a MIN VALUE or
MAX VALUE message appears for one second and the display shows the
middle current calibration point again. The display now shows the high current
calibration point.
18 Read the DVM and change the high current value on the display to match the
computed current (DVM reading divided by shunt resistance).
For example, if the computed value is 6.899 A, adjust the current to 6.899 A
using the knob and arrow keys.
I HI 6.8990 A
Notice that you should wait for the DVM reading to stabilize for accurate
calibration.
Notice that you should wait for the DVM reading to stabilize for accurate
calibration.
