1 Getting Started
28 Keysight N1911A and N1912A Installation Guide
4 Press
Network DHCP if you need to set any optional settings.
5 Press
Restart Network.
A pop-up appears for 5 seconds (see Figure 1-4). Monitor the Status at the
bottom of the display to see when the server has assigned an address.
Figure 1-4 LAN network restart pop-up
6 Press , to return to a measurement screen.
7 If you intend to program over LAN or use such programs, make sure you have
installed I/O software on your computer.
8 Use the Connection Expert utility of the IO Libraries Suite to add the power
meter and verify a connection. When identifying the instrument, it is easiest to
use the IP address that you noted in step 6 above.
9 You can use various programming environments to control the power meter.
For an overview about programming instruments via LAN, refer to the
connectivity guide.
If you have installed other I/O software, refer to documentation that
accompanies the software.
