90 Keysight N9927-90001 User’s Guide
NA (Network Analyzer) Mode
NA Mode Settings
How to select a multi-trace configuration
—Press Trace 6
—Then Num of Traces
— Then choose from the following:
The default measurements depend on the options that are installed
How to activate a trace in order to change a setting
—Use the arrows OR
—Press Trace 6
then select Trace 1, Trace 2, Trace 3, or Trace 4, Only traces
that are shown can be activated.
How to maximize the viewing of the active trace
—Press System 7
—Then Full Screen.
— Press any key to return to the standard display.
Quick Settings
Both CAT and NA Modes allow you to view and change most relevant settings
from a single location. All of these settings are discussed in this chapter and,
unless otherwise noted, ALL of these settings can also be made using the
standard softkey menus.
How to view and change Quick Settings
—Press Meas Setup 4
x1
1 trace standard configuration
x2
2 traces overlayed on a single graticule
x2H
2 traces on separate graticules
x3H
3 traces on separate graticules
x3
3 traces overlayed on a single graticule
x4H
4 traces on separate graticules
