IF input frequencies
The IF input frequencies are different depending on the DSP version.
With DSP version 4:
* RF or Transmitting frequency < 53 MHz: IF = 2.535211 MHz [3 x (60e6 / 71)]
* RF or Transmitting frequency > 53 MHz: IF = 7.605634 MHz [9 x (60e6 / 71)]
With DSP version 5, the IF frequency is dependent on the RF or
transmitting frequency and current IFBW setting:
Table 18
* All RF or transmitting frequency; IF bandwidth > 1 MHz
IFBW setting IF frequency
1 MHz 7.692 MHz
1.5 MHz 7.368 MHz
2 MHz 8.450 MHz
3 MHz 8.163 MHz
5 MHz 6.897 MHz
7 MHz 10.53 MHz
10 MHz 15.38 MHz
15 MHz 22.22 MHz
* IF bandwidth <= 600 kHz:
* RF or transmitting frequency < 53 MHz; IF = 2.479339 MHz [(3 x (100e6 / 121)]
* RF or transmitting frequency > 53 MHz; IF = 7.438017 MHz [(9 x (100e6 / 121)]
Manually change the IF frequency
The IF frequency can be changed to any value between +14.9999 MHz and – 14.9999
MHz using SENS:IF:FREQ (SCPI) or IFFrequency (COM) commands.
* With DSP Version 4 through 34 and above, min and max IF frequencies up to + 20.1
MHz are available.
* With DSP Version 5, min and max IF frequencies up to + 38 MHz are available.
* Performance is degraded drastically above + 14.999 MHz.
73 | Keysight | Antenna Test – Selection Guide

Keysight PNA Series Specifications

General

Number of Ports	2, 4
Impedance	50 Ω
Output Power Range	-55 dBm to +13 dBm (varies by model)
Dimensions	Varies by model
Weight	Varies by model
Power Requirements	100-240 VAC, 50/60 Hz
Storage Temperature	-40°C to 70°C
