Migration from 8510/8530 based antenna systems to PNA
network analyzer based systems
Table 3 shows the various system components of 8510/8530 based antenna systems
and their recommended replacement components. While the components listed are
recommended replacements, some interface requirements are different. Refer to the
“Antenna measurement design considerations” section on page 22 for interface
requirements.
4. Migrating from 8510/8530 to PNA
Table 3. Cross reference for 8510/8530 based antenna systems migrating to PNA network analyzer based systems
System Components Description Recommended PNA solution Description
8510C Network analyzer Determined by test set
8510C -008 Network analyzer with pulse
capability
Determined by test set
8514B 45 MHz – 20 GHz test set E8362C 10 MHz – 20 GHz
8515A 45 MHz – 26.5 GHz test set N5242A/E8353C 10 MHz – 26.5/40 GHz
8517B 45 MHz – 50 GHz test set E8364C 10 MHz – 50 GHz
85110A Pulsed 2 – 20 GHz test set N5242A Option 021, 025, and 008 10 MHz to 26.5 GHz
85110L Pulsed 45 MHz – 2 GHz test set N5242A Option 021, 025, and 008 10 MHz to 26.5 GHz
8530A Microwave receiver N5264A measurement receiver 10 MHz to 26.5 GHz
8511A 45 MHz – 26.5 GHz frequency
converter
N5280A 26.5 GHz with frequency converter
8511B 45 MHz – 50 GHz frequency
converter
N5281A 50 GHz with frequency converter
85105A mmWave test set controller N5260A mmWave test set and external
hardware
Q85104A 33 – 50 GHz test set module E8364C or OML head 10 MHz – 50 GHz
U85104A 40 – 60 GHz test set module E8361C or OML head 10 MHz – 67 GHz
V85104A 50 – 75 GHz test set module N5250A or OML head 10 MHz – 110 GHz
W85104A 75 – 110 GHz test set module N5250A or OML head 10 MHz – 110 GHz
8360 Series RF Sources None required
44 | Keysight | Antenna Test – Selection Guide
