4 Input/Output Functions
Input/Output
Key Path
Input/Output, Output Config, Trig 1/2 Output
Example TRIG1:OUTP OFF
Readback Off
Initial S/W Revision Prior to A.02.00
Sweeping (HSWP)
Selects the Sweeping Trigger signal to be output to the Trig 1 Out, or Trig 2 Out, connector when a
measurement is made. This signal has historically been known as "HSWP" (High = Sweeping), and is 5 V
TTL level with 50 ohm output impedance.
Key Path
Input/Output, Output Config, Trig 1/2 Output
Example TRIG1:OUTP HSWP
Readback Sweeping
Initial S/W Revision Prior to A.02.00
Measuring
Selects the Measuring trigger signal to be output to the Trig 1 Out, or Trig 2 Out, connector. This signal is
true while the Measuring status bit is true.
Key Path
Input/Output, Output Config, Trig 1/2 Output
Example TRIG1:OUTP MEAS
Readback Measuring
Initial S/W Revision Prior to A.02.00
Main Trigger
Selects the current instrument trigger signal to be output to the Trig 1 Out, or Trig 2 Out, connector.
Key Path
Input/Output, Output Config, Trig 1/2 Output
Example TRIG1:OUTP MAIN
Readback Main Trigger
Initial S/W Revision Prior to A.02.00
Gate Trigger
Selects the gate trigger signal to be output to the Trig 1 Out, or Trig 2 Out, connector. This is the source of
the gate timing, not the actual gate signal.
EMI Receiver Mode Reference 201
