Keysight PXA N9030A User Manual

9 Strip Chart Measurement
SPAN X Scale
SPAN X Scale
Displays the menu keys that enable you to control the span x scale parameters.
Key Path
Front-panel key
Notes Front panel only.
Initial S/W Revision A.07.00
Ref Value
Sets the ref value of the strip chart display.
Key Path
SPAN X Scale
Remote Command
:DISPlay:SCHart:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:RLEVel <time>
:DISPlay:SCHart:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:RLEVel?
Example DISP:SCH:VIEW:WIND:TRAC:X:RLEV –100 s
DISP:SCH:VIEW:WIND:TRAC:X:RLEV?
Couplings No
Preset 0 s
State Saved Saved in instrument state.
Min –1.1998 ks
Max 0 s
Initial S/W Revision A.07.00
Scale/Div
Allows you to set X scale/div of the strip chart display.
Key Path
SPAN X Scale
Remote Command
:DISPlay:SCHart:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:PDIVision <time>
:DISPlay:SCHart:VIEW[1]:WINDow[1]:TRACe:X[:SCALe]:PDIVision?
Example DISP:SCH:VIEW:WIND:TRAC:X:PDIV 1s
DISP:SCH:VIEW:WIND:TRAC:X:PDIV?
Preset 1 s
State Saved Saved in instrument state.
704 EMI Receiver Mode Reference
