TOS8870A
SPECIFICATIONS
39
7.3 Common Specifications
Table 7-5
Common Specifications
Types of test 1.AUTO ACW
→
IR Withstanding voltage test first and insulation resistance test next
2.AUTO IR
→
ACW Insulation resistance test first and withstanding voltage test next
3.MANUAL ACW Withstanding voltage test alone
4.MANUAL IR Insulation resistance test alone
Remote Control Test / Reset control Low active control
Input conditions
*1
*1. The input terminal is pulled up to +15 V supply voltage by resistor. Opening of the input terminals is equivalent to
a high level input.
• High level input voltage 11 V to 15 V
• Low level input voltage 0 V to 4 V
• Low level sweep out current 5 mA or less
• Input pulse width 20 ms minimum
Interlock Protection is effected when INTERLOCK terminal is made open
(test is disabled).
Output signals
*2
*2. The rating of the signal contacts is 125 VAC, 1 A, or 30 VDC, 1 A.
Loudness of the buzzer is adjustable with a knob in common for the PASS signal and FAIL alarm.
Signal Name Conditions for Signal Generation Type of Signals
TEST ON signal Delivered during entire test-on period. Make-contact signal and lamp
PASS signal Delivered when PASS judgment is
made, for approximately 50 ms.
Make-contact signal, lamp and buzzer
ACW/FAIL alarm Delivered continuously when FAIL
judgment of withstanding voltage test
is made.
Make-contact signal, lamp and buzzer
IR/FAIL alarm Delivered continuously when FAIL
judgment of insulation resistance test
is made.
Make-contact signal, lamp and buzzer
READY signal Delivered when in the READY state. Make-contact signal
Special Test Mode 1.DOUBLE
ACTION
Test starts only when the START switch is pressed within approximately 0.5 s
after pressing the STOP switch.
Selectable with 2.PASS HOLD The PASS state is held.
DIP switches at 3.MOMENTARY Test is executed only during the period the START switch is kept pressed.
rear of Tester 4.FAIL ALARM FAIL alarm and PROTECTION state cannot be reset by the remote-control
STOP signal.
Ambient Temperature and Humidity Specification range 5 ˚C to 35
°
C /20 % to 80 % RH
Operable range 0 ˚C to 40
°
C /20 % to 80 % RH
Storage range -20 ˚C to 70
°
C /80 % RH or less
