VIII Table of Contents TOS8870A
Table of Contents
To supervisor in charge of operation .......................................................... I
For your own safety (How to avoid electrification) .....................................I
Power Requirements of this Product ......................................................... II
Safety Precautions ................................................................................... III
Safety Symbols ........................................................................................VI
Overvoltage category ..............................................................................VII
INTRODUCTION ....................................................................................... 1
Chapter 1 SETUP
1.1 Checking for Shipping Damages and Accessories ............................................ 2
1.2 Precautions for Installation ................................................................................. 2
1.3 Precautions for moving ...................................................................................... 3
1.4 AC Line Requirements ....................................................................................... 4
1.5 Connecting the AC Power Cord ......................................................................... 5
1.6 Grounding .......................................................................................................... 5
Chapter 2 WARNINGS AND CAUTIONS FOR OPERATING THE
TESTER
2.1 Preparative Procedures ..................................................................................... 6
2.1.1 Wearing Insulation Gloves ....................................................................... 6
2.1.2 Grounding the Tester ............................................................................... 6
2.2 Warnings and Cautions when Operating the Tester .......................................... 7
2.2.1 Connecting of test lead-wire on LOW side............................................... 7
2.2.2 Connection of test lead-wire on high-voltage output side ........................ 7
2.2.3 Power switch ............................................................................................ 7
2.2.4 Change of test condition .......................................................................... 7
2.2.5
Suspension of testing
............................................................................... 8
2.2.6 Critical areas of the Tester under operation............................................. 8
2.3 Warning after the output has been cut off .......................................................... 8
2.3.1 Confirmation on completion of testing..................................................... 8
2.3.2
Cautions in electric charging in insulation resistance test
........................ 9
1) Electric charging ............................................................................................................... 9
2) Consideration of discharge time........................................................................................ 9
2.4 Remote controls of the Tester .......................................................................... 10
2.5 Inhibitions ......................................................................................................... 10
2.5.1 Inhibition of rapid ON/OFF repetitions ................................................... 10
2.5.2 Inhibition of shorting to earth ground ..................................................... 10
2.6 Emergency handling ........................................................................................ 10
2.7 Troubleshooting ............................................................................................... 10
2.7.1 In case of trouble ................................................................................... 10
2.7.2 Fade out of DANGER lamp.................................................................... 11
2.8 Attention for Trouble-Free Operation ............................................................... 11
