SPECIFICATIONS
TOS8870A
Table 7-6
*1. Only on models that have CE marking on the panel.
Not applicable to custom order models.
*2. This instrument is a Class I equipment. Be sure to ground the protective conductor terminal of the instrument. The
safety of the instrument is not guaranteed unless the instrument is grounded properly.
*3. Can be factory-modified to nominal 110 V, 120 V, 220 V, 230 V and 240 V.
*4. Power consumption of the instrument modified to operate on an AC line voltage other than 100 V is as follows.
110 V / 120 V: 25 VA or less
220 V / 230 V / 240 V: 45 VA or less
Safety
*1, *2
Conforms to the requirements of the following directive and standard.
Low Voltage Directive 73/23/EEC
EN61010-1
Class I
Pollution degree 2
EMC
*1
Conforms to the requirements of the following directive and standard.
EMC Directive 89/336/EEC
EN61326
EN61000-3-2
EN61000-3-3
Under following conditions
1. Used HV test leadwire TL01-TOS.
2. No discharge in testing.
Power Require-
ments
Line voltage
100 VAC
±
10 %, 50/60 Hz
*3
Power consumption
When no load (RESET state) : 15 VA or less
*4
When with rated load : Approx. 600 VA
Insulation resistance 30 M
Ω
or more, 500 VDC
Withstanding voltage 1390 VAC (2 seconds), between AC line and chassis
Dimensions See the outline drawing.
Weight Approx. 23 kg
Accessories TL01-TOS High Voltage Test Leadwires, approx. 1.5 m long. 1
AC Power cord 1
Operation Manual 1
Options RC01-TOS Remote Control Box
RC02-TOS Remote Control Box
HP01A-TOS High Voltage Test Probe, approx. 1.5 m long
HP02A-TOS High Voltage Test Probe, approx. 3 m long
TL02-TOS High Voltage Test Readwires, approx. 3 m long
KRB150-TOS Rackmount Bracket (for JIS)
KRB3-TOS Rackmount Bracket (for EIA)
