Dispersing units (choice)
PT-DA
07/2EC-E107
PT-DA
12/2EC-E123
PT-DA
12/2EC-E157
PT-DA
12/2MEC-E157
PT-DA
12/2WEC-E157
Shaft length, mm
107
123
123
123
123
Stator/Rotor Ø,
mm
7.8/5
12/9
12/9
12/9
12/9
Processing
volume
Ca.
0.5 – 10 ml
Ca.
3 – 250 ml
Ca.
3 – 250 ml
Ca.
3 – 250 ml
Ca.
3 – 250 ml
Notes
-
-
-
Knife Rotor
W-Geometry
Temperature
up to about 90 °C processing temperature
Pressure
not pressurised
Materials
stainless steel 1.4435 (316L) and PTFE compound
Cleaning
can be sterilised by all the usual methods, e.g. autoclave
Product
requirements
The product to be dispersed must be pumpable and fluid and must not
contain any solid particles that might destroy the attachment.
3.3 STAND ST-P01/200
POLYTRON

PT 1300 D handhelds can be supplemented with the joint stand ST-
P01/200. The stand consists of the following components:
 Baseplate
 Pivotable articulated arm with the possibility of right, left, up, down movement
 Motor mounting with adjustable pitch up to approx. 15°
The stand should allow for a higher degree of flexibility at the workplace. The drive only
needs to be plugged into the provided socket.
 Make sure that the dive cable is attached to the cable holder
on the arm so that it can not enter into the working area.
 Make sure that the mounting screw on the rear side of the
stand has been tightened firmly so that the stand arm cannot
move away during operation. (see the installation drawing
enclosed)
See under Appendix, Chapter 10
