Make sure that the mounting screw on the rear side of the
stand has been tightened firmly so that the stand arm cannot
move away during operation. (see the installation drawing
enclosed)
3.6 TECHNICAL SPECIFICATIONS
POLYTRON

PT 1300 D
motor type
Brushless DC-motor, electronically commuted
supply voltage
90-260VAC
fuse
2.5 A T (Passive)
supply frequency
50/60 Hz
input power
100 W
output power
50 W
max. speed
2'000 to ca. 30'000 rpm infinitely adjustable
direction of rotation
clockwise, seen from above
ambient temperature
0 – 40°C
relative humidity
Max. rel. 95%
standards
EMV: certified by IEC/EN 61000-6-1 / 61000-6-3 / 61326-1
Safety: certified by IEC/EN 61010-2-51 & 61010-1
protection type
IP 20
max. period of continuous
operation
100%
Noise emission
 70 dB (A) with full rotational speed with aggregate
PT-DA12/2EC-E157 in H
2
O
ON/OFF Switch
separate at control- and operating module
Current consumption
max. 0.5 A at 230 V
max. 1 A at 100-120 V
Interface
Standard MODBUS, Optional RS 232
weight (drive only)
control module 1033 g / operating module 568 g
