Kinematica POLYTRON PT 1300 D - Implementation

OI PT 1300 D English / Edition 3.0 / 23.10.2009
Page 34 of 37
11 APPENDIX
This chapter regards only units wit MODBUS Protocol respectively unitsw with following
item number
Item number
Description
11010030
PT 1300 D MODBUS (with CH-Connector)
11010031
PT 1300 D MODBUS (with EU- Connector)
11010039
PT 1300 D MODBUS (with UK- Connector)
11.1 IMPLEMENTATION
11.1.1 SLAVE-ADDRESS
The PT1300D has the fix address 0x01. The Broadcast-Address (0x00) is supported to,
but only with the command 0x06, as by the Broadcast-Addressing only no replay
acceptable is.
11.1.2 READ HOLDING REGISTER
More than one Register can be read out with one instuction codeUm mit dem PT3100D-
Programm kompatibel zu sein, wurde die Abfrage von mehreren Registern mit einer
Abfrage implementiert.
Instruction code
Registeraddress
Remarks
0x03
0..15
only Register 0..10 busy, Rest are writing with
0x0000
11.1.3 WRITE SINGLE REGISTER
In the PT1300D is a write single register integrated.
Instruction code
Registeraddress
Remarks
0x06
0..2
--
