OI PT 1300 D English / Edition 3.0 / 23.10.2009
To remove the aggregate from the drive, push the retaining ring of the coupling upward
and/or in the direction of the drive. At the same time, the aggregate is to be carefully pulled
downward in the axial direction so that the homogenizing aggregate is not tilted in the
coupling housing (see the enclosed assembly sketch).
WITH PUSHING UP OF THE COUPLING RING, THE
AGGREGATE CAN UNINTENTIONALLY FALL OUT OF THE
COUPLING. FOR THIS REASON, ALWAYS HOLD IT WITH
ONE HAND.
THE SAW-TEETH OF THE STATOR ARE GROUND TO BE
SHARP. THERE IS THE DANGER OF INJURY WITH
IMPROPER HANDLING.
4.3 WORKING WITH THE PT 1300 D
Connect your corresponding homogenising aggregate.
Along with the drive unit, you also have the control in your hand. Firstly check for a
proper connection of the supply and control module and the drive unit, then switch
on the main switch on the supply and control module (green light).
When you turn on, the display shows the selected firmware version for example
C01
POLYTRON
-DISPERSING AGGREGATES MAY NOT BE
USED IN THE DRY STATE – THE LOWER SLIDE BEARING
ARE COOLED AND LUBRICATED BY THE LIQUID PHASE
OF THE PROCESSES MEDIUM.
Guide the connected aggregate into the medium to be processed. The optimal
submersion depth of the aggregate is approx. 2/3 below the liquid surface and 1/3
above the vessel bottom. By submerging at an angle of approx. 15°, the degree of
effectiveness can additionally be improved.
