3.4 STAND ST-P12/600
POLYTRON

P T 1300 D handheld units can be used with the optinal plate stand ST-
P00/200. The stand consists of the following components:
 Baseplate
 Stand column with a maximum stroke of about 550mmMotor mounting with
 drive holder with the option of left, right, up and down movement
The stand should allow for a higher degree of flexibility at the workplace. The drive only
needs to be plugged into the provided socket.
As an option, the following components are available:
 Cross sleeve complete for the attachment of a vessel holder
 Vessel holder
 An adjustment ring for precise positioning of the handset
Make sure that the mounting screw on the rear side of the
stand has been tightened firmly so that the stand arm cannot
move away during operation. (see the installation drawing
enclosed)
See under Appendix, Chapter 10
3.5 STAND ST-P15/320
POLYTRON

PT 1300 D handheld units can be used with the optinal plate stand ST-
P15/320. The stand consists of the following components:
 Baseplate with stand
 Drive holder with the possibility of moving up and down
 Ability to provide the base station to the base plate
The stand should allow for a higher degree of flexibility at the workplace. The drive only
needs to be plugged into the provided socket.
