9 GUARANTEE
The symbol of the crossed refuse container signifies that the product in the
European Union to must be supplied to separate collection. Labeled
products must not be disposed with household waste, rather must be left at
a collection point for recycling electrical and electronic equipment. Recycling
helps to reduce the consumption of raw materials and to protect the
environment.
10 APPENDIX
10.1 LEGEND TO THE DRAWINGS OF PT-DA 05/2EC, 07/2EC, 12/2EC, 12/2 Z MEC
Positionen
1
2
3
4
PT-DA 05/2 EC..
Drawing-No.
BA.004-001-3
Stator tube
Drive shaft
Slide bearing
Slide disc
PT-DA 07/2 EC..
Drawing-No.
BA.004-002-3
Slide disc
PT-DA 12/2 EC..
Drawing-No.
BA.004-003-3
Rotor
PT-DA 12/2 .. EC..
Drawing-No.
1.012-0195-3
Rotor
