Breva EN 11/20
11.10. Using Programs
The device KINETEC
®
Breva allows you to store up to 16 programs (numbered 1 to 16), including
the type of movement, ROM, speed, force, pauses and timer.
The original parameter values of the program are empty. These values can be modified and
saved at any time (see ‘To enter a program’, page 9)
Beginning
Keys to
press
Display Remarks
To stop the unit
PL/FLEX DOR/FLEX
20 STOP 5 20
Check that the hand control is not
locked (See page 7).
To access program mode
PROGRAM 1
EMPTY
The program number blinks.
To change the program if necessary or
PROGRAM 10
20 PL/DOR 0
The new program number blinks.
To exit and confirm the selected program
PL/FLEX PL/FLEX
20 STOP 5 0
The current parameters are those
recorded in program 10.
To exit without confirming the selected
program
PL/FLEX DOR/FLEX
20 STOP 5 20
Back to the starting parameters.
To start the unit
PL/FLEX PL/FLEX
20 STOP 10 0
The angle display changes with the
current movement.
11.11. Reading the values of a program: e.g. SPEED
Beginning
Keys to
press
Display Remarks
To stop the unit
PL/FLEX PL/FLEX
20 STOP 10 0
Check that the hand control is not
locked (See page 7).
To access program mode
PROGRAM 1
EMPTY
The program number blinks.
To change the program if necessary
or
PROGRAM 10
20 PL/DOR 0
The new program number blinks.
To read the speed value
PROGRAM 10
SPEED: 1
Displays the speed value.
After 5 seconds or after pressing on another
key
PL/FLEX PL/FLEX
20 STOP 10 0
To exit and confirm the selected program
PL/FLEX PL/FLEX
20 STOP 10 0
The current parameters are those
recorded in program 10.
To start the unit
PL/FLEX PL/FLEX
20 STOP 10 0
The angle display changes with the
current movement.
Comments:
• The values shown in the ‘Display’ column are examples. They actually depend on the stored
programs.
• The current movement parameters can be changed while using that program but no data will
be stored in the original program. See programming mode (page 9) to modify programs.
