Breva EN 18/20
14.5. Technical specifications
Product:
Lifespan of the machine: 12 years
Weight: 10.9 kg (24 pounds)
Splint dimensions: 56cm (22in.) x 37cm (14.5in.) x 45cm (17in.)
Angular limits: see page 7
Speeds: from 50 to 150° per minute
Foot sizes: from 19cm (7.5in.) to 29cm (11.4in.)
Maximum weight of the user: 135 kg (297 pounds)
Acoustic pressure: <70dB
Electricity:
Power supply: 100-240V~
Frequency: 50-60 Hz
Power consumption: 50 VA
Class: Device of Type BF Class II or Type B Class I
Protection classification: IP 20 (Protected against solid objects greater than 12.5mm,
but not protected against liquids)
Fuse: T 750mA 250V 6.3 x 32mm (Kinetec order: 4610007434)
Environment:
Storage/transport conditions: Temperature: -25 to 70°C / -13 to 158°F.
Relative humidity: up to 93% without condensation.
Operating conditions: Temperature: 5 to 40°C / 41 to 104°F.
Relative humidity: 15% to 93% without condensation.
Atmospheric pressure: 700 hPa to 1060 hPa.
14.6. Symbols used
CAUTION
(consult the accompanying
documentation)
Speed
Flexion limit
STOP (power off)
Timer
Warm up
ON (power on)
Force
Modulation
Start movement
Pause
ByPass
Stop movement
Increase
Key for
Plantar Flexion/Dorsiflexion movement
Program access
Decrease
Eversion/Inversion movement
Right way up when box is stored
Extension limit
~
Alternating current
Contains electric and electronic
components; do not throw away with
household refuse.
Fragile
Keep dry during storage or transport
Temperature Limit during storage or
transport
Follow the instructions for use
Follow the instructions for use
Class II device
TYPE BF device
(protection against electric shocks)
TYPE B device
(protection against
electric shocks)
14.7. Warranty
The device KINETEC warranty is strictly limited to the replacement, free of charge, or to factory repairs of part(s)
recognised as defective.
KINETEC guarantees its continuous passive motion systems for 2 years against all defects of manufacture from
the date of purchase by the consumer.
KINETEC is the only organization able to assess the application of the warranty to its systems.
The warranty will be considered null and void if the device has been used abnormally or under conditions of use
other than those indicated in the user's manual.
The warranty will also be considered null and void in the event of deterioration or an accident due to
negligence, inappropriate surveillance or inappropriate maintenance, or due to transformation of the
equipment or an attempt to repair the equipment.
