Kinetec Breva - Eversion; Inversion

Breva EN 16/20
13.2. Eversion / Inversion
The device KINETEC
®
Breva provides movements from 25° of abduction to 25° of adduction, with a
Valgus/Varus component.
Loosen the button (4).
Position the motor as shown above.
Tighten the button (4).
Position the Extension/Flexion footplate as shown. A label
indicates which footplate is to be used.
The green indicator (32) shows when it is in the correct
position.
Position the synchronization bar (33) in its
guide (34) and tighten the knob (35).
Setting up the patient.
Adjust the slope of the splint with the
button (7), in either the sitting or lying-
down position.
Adjust the calf support position (1)
with the knobs (2) and (4). The calf
support slope is free.
• Select the Eversion/Inversion movement:
- Press and set the movement parameters (see page 8).
- or select a program (see page 11).
32
32
4
7
1
2
4
33
34
35
