Kinetec Breva - Possible Movements; Extension; Flexion

Breva EN 15/20
13. Possible movements
13.1. Extension / Flexion
The device KINETEC
®
Breva provides movements from 40° of plantar flexion to 30° of dorsiflexion.
Loosen the button (4).
Position the motor as shown above.
Tighten the button (4).
Position the Extension/Flexion footplate
as shown. A label indicates which
footplate is to be used.
Setting up the patient.
Adjust the slope of the splint with the
button (7), in either the sitting or
lying-down position.
Adjust the calf support position (1)
with the knobs (2) and (4). The calf
support slope is free.
The knob (31) allows the depth of
the foot to be adjusted.
• Select the Extension/Flexion movement:
- Press and set the movement parameters (see page 8).
- or select a program (see page 11).
4
31
7
1
2
4
31
