Breva EN 7/20
11.3. START / STOP / REVERSE function
As with all KINETEC systems, the device KINETEC
®
Breva is equipped with a START/STOP/REVERSE
function.
Press the key of the hand control. The movement stops,
Press the key of the hand control. The movement starts in the opposite direction.
CAUTION
For optimum safety, always give the hand control to the patient before starting the system.
11.4. Procedure to stop the machine:
To stop the machine's movement: press the key
To switch the unit off: press the ON / OFF switch (11) (see page 6)
11.5. Locking-Unlocking the hand control setting
The hand control allows the patient to control the machine as appropriate.
Simultaneously press the and keys to lock the hand control.
The display reads "LOCK", you cannot change the parameters; if you try, the message "LOCK"
will be displayed.
To unlock the hand control, simultaneously press the and keys, the display reads
"UNLOCK”.
We recommend that you lock the hand control when you give it to the patient.
Note: hand control locking is preserved when you switch the unit ON/OFF.
11.6. Possible values for each parameter
Possible values Default setting
Plantar
Flexion/Dorsiflexion
Inversion/Eversion Plantar Flexion/Dorsiflexion Inversion/Eversion
• Lower limit
Plantar Flexion 40°
Dorsiflexion 25°
25° ’inversion to
20° eversion, right foot
25° eversion to
20° inversion, left foot
Plantar flexion 20°
10° Inversion or Eversion,
depending on the foot
• Upper limit
Plantar Flexion 35°
Dorsiflexion 30°
20° ’inversion to
25° eversion, right foot
20° eversion to
25° inversion, left foot
Dorsiflexion 0°
10° Eversion or Inversion,
depending on the foot
• Speed 1 to 5 (from 50 to 150° per minute) 2
• Force 1 to 6 6
• Extension pause 0 to 900 seconds (15 minutes) 0
• Flexion pause 0 to 900 seconds (15 minutes) 0
• Timer No timer (00H00) to 24H00 0
