Kingtel KT52IP - Page 58

TFTP example for remote xml mode: Set the Phonebook Name as Fanvil - Server URL is
tftp://192.168.1.3/admin/phonebook/index.xml.
Remote Phonebook Settings
Phonebook Name
Phonebook name displayed on the phone.
Server URL
Server url of the remote phonebook.
SIP Line
SIP line for the remote phonebook.
User/password
Authentication username and password.
LDAP Settings
Display Title
The name displayed on the LCD.
Version
LDAP protocol version; supports 3 as default.
Server Address
LDAP server address.
Server Port
LDAP server port.
Authentication
depending on the server’s authentication mode. There are
NONE,DIGEST-MD5,CRAM-MD5,SIMPLE
Line
Assigned SIP line for the LDAP dialing
Username
User name for LDAP authentication
Password
Password for LDAP authentication
Search Base
Search data directory
Enable Calling Search
Allow LDAP contact search and disply LDAP contact name
during dialing and incoming call.
Telephone
Display LDAP contact’s telephone number
