Kingtex FT Series User Manual

6-8 設定送布齒高度 SETTING THE HEIGHT OF FEED DOG
圖
送布齒
針板
1～1.2mm
M
FEED DOG
NEEDLE PLATE
15
7. 裝飾縫 TOP COVERSTITCH
B. 結線鉤安裝的角度為當結線鉤向左擺動掛線鉤與左針交會時，與左針間隙為 0.5-0.8mm，再繼續向
SCREW
左擺動到行程的最左端時掛線鉤距左針中心為 4.5-5.5mm。
WHEN SPREADER MOVE TO THE LEFT AND PASSES BEHIND THE LEFT NEEDLE,THE CLEARANCE IS
0.5- 0.8 mm. AND WHEN SPREADER REACHES THE EXTREME LEFT,THE DISTANCE BETWEEN TIP
7-1 上裝飾縫結線鉤安裝及定位
OF HOOKING PART AND THE CENTER OF LEFT NEEDLE IS 4.5-5.5 mm.
INSTALLING AND SETTING THE SPREADER
A. 結線鉤安裝高度為距針板面 9-11mm。
THE HEIGHT OF SPREADER IS 9-11 mm ABOVE THE SURFACE OF NEEDLE PLATE.
4.5～5.5mm
SPREADER
0.5～0.8mm
TIP
SURFACE OF
NEEDLE
PLATE
SPREADER
THE ADJUSTMENTS ARE MADE BY LOOSENING SCREW (A) FOR THE HEIGHT OF LOOPER AND
LOOSENING SCREW (B) FOR MOVING POSITION OF LOOPER.
飾縫結線鉤
掛線鉤
針板面
鎖緊螺絲
固定螺絲
A圖 B圖 C圖
SCREW
(A)
(B)
M. 送布齒在行進路徑的最高點時，前後兩送布齒必須同一高度並且平
行針板，同時浮出針板面 1.0-1.2mm。
WHEN FEED DOGS RISE TO THE UPPER MOST,THEIR HEIGHT OF
FEED DOGS IS 1 - 1.2 mm ABOVE THE SURFACE OF NEEDLE
PLATE AND DIFFERENTIAL AND MAIN FEED DOG ARE PARALLEL
TO THE SURFACE OF NEEDLE PLATE.
C. 調整時，可放鬆結線鉤鎖緊螺絲及擺動臂固定螺絲，來調整結線鉤的上下及擺動位置。
9~11mm
