OPERATION
5
3. When the cylinder is contracted,
the hydraulic fluid returned from
the cylinder is drained to the trans-
mission through the draining circuit
as the operating lever is operated
to the opposite direction from the
expansion position.

It is recommended to use the
double acting cylinder instead
of the single acting cylinder if
the implement will be operated
frequently and continuously.
If using the single acting cyl-
inder too frequently or for an
extended period of time, the
hydraulic fluid can be over-
heated, resulting in deteriora-
tion of the hydraulic parts’ du-
rability as the main relief valve
opens at cylinder contraction.
IMPORTANT
CONNECTING AND DISCONNECTING IMPLEMENT HYDRAULIC HOSE
CONNECTION
1. Make sure to stop the engine be
-
fore connecting hydraulic hoses.
2. Move the double acting valve le
-
ver forward and backward for 4
to 5 times to release the pressure
in the hydraulic line of the tractor.
Otherwise, it is hard to connect the
couplers, and hydraulic uid can be
sprayed from the line and get in to
your eyes while connecting them.
3. Remove any foreign material around
the male and female couplers. If
foreign material enters the hydrau-
lic components, it can lead to mal-
function of the system.
4. Open the dust-proof cover of the
female coupler of the tractor and
insert the male coupler of the im-
plement. A clicking sound is heard
when the couplers are engaged.
5. Pull the hydraulic hose of the im-
plement to check that the couplers
are properly connected.
6. Start the engine and check the op-
erating status and leakage.
DISCONNECTION
1. Make sure to stop the engine be
-
fore disconnecting implements.
2. Release any residual pressure in the
hydraulic hoses of the implement
and tractor by operating the double
acting valve lever 4 to 5 times.
3. Remove any foreign material
around the couplers.
4. Low e r t he im ple men t on th e
ground or remove any external
load applied to the implement. Dis-
connecting hoses while outer load
is applied to the implement is very
difcult and dangerous due to the
pressurized uid in the hose.
5. Remove the male coupler by push-
ing the female coupler boss of the
tractor backward.
6. Close the dust-proof cover of the
female coupler of the tractor. Wrap
the male coupler of the implement
with a plastic bag to prevent con-
tamination.
