1. Check engine oil daily.
2. Park the tractor on level ground
and lower implement.
3. If the engine was just running,
wait for approx. 10 minutes before
checking the oil level.
tb2O701A
CHECKING ENGINE OIL LEVEL (E)
(1) Oil Inlet Plug (2) Gauge
(A) Oil level is acceptable within this range
To avoid personal injury:
Be sure to stop the engine be-
fore checking the oil level.
CAUTION
4. Pull out the oil dipstick, clean it,
and then insert it into its original
position. Then, pull it out again and
check if the oil level is within the
specied range.
5. If the oil level is too low, add some
fresh oil so that the level is within
the allowable range. (Refer to "Lu-
brication" in the chapter "Service")
(1) Oil Dipstick
(A) Upper Limit (B) Lower Limit
tb2O702A
To Next Page
