M46O706A
(1) Oil Dipstick
(A) Upper Limit (B) Lower Limit
1. Park the machine on a at surface,
lower the implement and shut
"OFF" engine.
2. Depress the brake pedals and ap-
ply the parking brake.
3. Set all shift levers into the neutral
position.
4. Stop the engine.
(1) Gauge (2) Oil Filler Plug
(A) Oil level is acceptable within range
CHECKING TRANSMISSION FLUID LEVEL (D)
5. Pull out the oil dipstick, clean it,
and then insert it into its original
position. Then, pull it out again and
check if the oil level is within the
specied range.
6. If the oil level is too low, add some
new oil so that the level is within
the allowable range. (Refer to
"Replacing transmission fluid and
lter" in the chapter "Service")
If oil level is low, do not run en-
gine.
Never add the oil over the up-
per limit.
IMPORTANT
M46O705A
To Next Page
