CS2510H/CS2610H
3. Float
The floating function is activated
when the joystick lever is pushed
one position further from the down
position. When the lever is in this
position, the boom moves up and
down freely along the surface of
the ground as the hydraulic line is
opened from the valve to the boom
cylinder. This function is useful
when removing soft objects on
hard ground. (For example, when
removing snow or sand on an
paved road or removing night soil
on the ground in a stall)

If moving the lever to the oat-
ing position while the boom is
up in the air, the boom can fall
freely and lead to an accident.
WARNING
4. Fast dump
The fast dump function is activated
when the joystick lever is pushed
one position further to the right
from the dump position.
5. Down & roll back
The boom can be lowered and the
bucket can scoop up by operat-
ing the joystick lever to the front
left position (10 o’clock position).
However, the operation time may
not be shortened much since the
boomisloweredrstandthenthe
bucket is rolled back due to unbal-
anced hydraulic pressure in the
hydraulic circuit.
6. Down & dump
The boom can be lowered and the
bucket can dump by operating the
joystick lever to the front right posi-
tion (2 o’clock position). However,
these two operations may not be
performed simultaneously due to
unbalanced hydraulic pressure in
the hydraulic circuit.
7. Up & roll back
The boom can be lifted and the
bucket can scoop up by operating
the joystick lever to the rear left
position (7 o’clock position). How-
ever, these two operations may not
be performed simultaneously due
to unbalanced hydraulic pressure
in the hydraulic circuit.
8. Up & dump
The boom can be lifted and the
bucket can dump by operating the
joystick lever to the rear right posi-
tion (5 o’clock position). However,
the operation time is may not short-
ened much since the bucket dumps
rstandthentheboomislifteddue
to the unbalanced hydraulic pres-
sure in the hydraulic circuit.
9. Locking/unlocking joystick
Pressing the joystick lock lever in
locks the joystick while pulling it
outward unlocks the joystick as
showninthegure.
