4
-15DESCRIPTION OF OPERATING SYSTEM
WARNING
!!
!!
!
TILTING STEERING LEVER
The steering wheel can be adjusted to
the driver's preference. Adjust it prop-
erly by pressing the tilt pedal lightly by
foot.
Do not adjust the tilt steering
while driving.
(1) Tilt Pedal
S43O432A
BRAKE PEDAL(RIGHT AND
LEFT)
(1) Brake Pedal (L) (3) Brake Lock
(2) Brake Pedal (R)
1. Before operating the tractor on a
road, be sure to interlock the right
and left pedals. It is dangerous to
use only one brake.
2. Use individual brake to assist in
making sharp turns. Disengage the
brake lock and depress only the
brake pedal that corresponds to the
direction you are turning.
S43O431A
3.When operating the tractor on roads,
always be sure to interlock the left
and the right brake pedals. Do not
forget to observe this precaution,
stepping on only one brake while op-
erating on roads can cause an acci-
dent resulting in personal injury or
death.
