H11O608A
4. Pull out the oil dipstick, clean it,
and then insert it into its original
position. Then, pull it out again and
check if the fuel level is within the
specied range.
5. If the oil level is too low, add some
new oil so that the level is within
the allowable range. (Refer to "Lu-
brication" in the chapter "Service")
(1) Oil Dipstick
(A) Upper Limit (B) Lower Limit
When using oil of different
maker or viscosity from the
previous one, remove all of
the old oil. Never mix two dif-
ferent types of oil.
Do not start the engine if the
amount of oil is insufcient.
Wipe the oil dipstick with
clean
cloth or tissue. If foreign
material enters the tank, it can
lead to malfunction of the en-
gine.
Never add the oil over the up-
per limit of the tank.
•
•
•
•
IMPORTANT
1. Check the engine oil daily.
2. Park the tractor on a level ground
and lower the implement.
3. If the engine was just running,
wait for approx. 5 seconds before
checking the oil level.
CHECKING ENGINE OIL LEVEL (D)
(1) Oil Inlet Plug (2) Gauge
(A) Oil level is acceptable within this range
TE1O704A
To avoid personal injury:
Be sure to stop the engine be-
fore checking the oil level.
•
CAUTION
To Next Page
