Chapter 1 Before Use 1-5
1. 4 Specifications
1. 4. 1 General
Subject Specification
Model KIP 7100
Configuration Console
Power consumption
(Maximum)
1,440W (US model)
1,680W (EU / Asia model)
(scanner / controller included)
Power consumption
(Low power mode)
30W or less
Acoustic noise Idling Max. 60db
Printing Max. 65db
(impulse sound excluded) EN ISO 7779
Ozone Max. 0.05ppm (Measurement method under UL Standard)
Dimensions 1346mm (Width) x 704mm (Depth) x 1105mm (Height)
(UI, Tray excluded)
Weight About 244kg (538lb)
Environmental condition
for usage
(Temperature)
10 to 32 degrees Centigrade / 50 to 89.6 F
(Humidity)
15 to 85% RH
Interface Network Interface (10 BASE-T / 100 BASE-TX / 1000 BASE-T)
Rating Input Power In the US : 120V plus/minus 10%, 50/60Hz, 12A
In Europe : 220-240V plus 6% or minus 10%, 50/60Hz, 7A
NOTE
The above specifications are subject to change without notice.
