Chapter 3 Error Correction 3-4
4. Slide the green Cutter Knob (6) fully from one side to the other to make a new straight edge.
Remove the cut portion.
5. Gently close Roll Deck.
NOTE
Completely slide Cutter Knob (6) until it stops at either end.
Not doing so may cause a paper jam.
Correct Wrong
NOTE
Be sure to close the Roll Deck fully until it locks at the correct position.
A paper jam may occur if it is not locked firmly.
6
6 6
