Chapter 3 Error Correction 3-12
6. Hold the gray areas (4) and release the Fuser Door (5).
Pull and remove the jammed print to the rear.
7. Close Fuser Door (5) and Exit Cover (3).
WARNING
There are extremely hot parts inside the Fuser Door.
Do not touch any parts in the Heater Unit, or you will be burnt.
Also be careful not to get burnt when you touch the printing paper as it may be very hot.
NOTE
If removed a mis-fed paper inside the Fuser Door, scattered toner can be adhered to the
next print.
4
5
jammed print
5
3
To Next Page
