Chapter 2 Basic Operations 2-16
8. Slightly pull Toner Cartridge rightward and insert the swelling tab in the arrowed slot.
9. Rotate Toner Cartridge to the arrow direction in 180 degrees or more.
(The new Toner Cartridge is closed firmly so as
not to lose the toner during the transportation)
10. Push in Upper Frame Unit firmly. Close the Manual Table.
NOTE
Even if the Joint is not fit to the Toner Cartridge,
when you turn on the printer, it is automatically fit
properly.
1
2
Manual Table
Upper Frame Unit
To Next Page
