Kirisun DR600 Service Manual

DR600 Service Manual
1DG1-DSM3MA1
Patch normal diode
1
D2
1DR1-SMCJ20A Patch diode 1 D1
1DR1-SS36 Patch commutation diode 1 D3
1DS1-DA2S10100L Patch switch diode 4 D8, D11, D12, D13
1DS1-HVC131
Patch switch diode
2
D9, D15
1DP1-BV03C TVS diode 1 D10
1DS1-DAN222 Patch switch diode 1 D14
1DR1-MMBZ20VALT1G TVS diode 6 D16, D17, D18, D19, D20, D5
1TT1-2SA1641-S
Patch triode
1
Q42
1DS1-DA204U Patch switch diode 2 D7, D21
5FE1-BLM15AG221SN1D EMI suppression filter 50
FB1, FB2, FB3, FB4, FB5, FB17, FB18, , FB25, FB26, FB27,
FB28, FB29, FB30, FB31, FB35, FB36, FB37, FB38, FB39,
FB40, FB41, FB42, FB43, FB44, FB45, FB46, FB47, FB48,
FB49, FB50, FB51, FB52, FB53, FB54, FB55, FB56, FB57,
FB58, FB59, FB60, FB62, FB63, FB64, R77, R84, R85, R86,
R87, R88, R89
5FE1-BLM41P600SPT EMI suppression filter 7
L8, L10, L11, FB20, FB22, L14, L15
5FE1-BLM18PG181SN1 EMI suppression filter 16
FB6, FB7, FB8, FB9, FB10, FB11, FB12, FB13, FB14, FB15,
FB19, FB21, FB24, FB61, FB33, FB34
2RS1-16-000O Flake resistor 18
C241, C320, R208, R231, R332, R213, R217, FB16, R22, R24,
R209, R210, R214, R224, R225, R94, R107, R109
3FW1-42932-302320 Patch fuse 1 F1
4PE1-16-F5
Patch LED
4
LED2, LED3, LED4, LED5
4PE1-16-F2 Patch LED 1 LED6
2LG1-NR8040T842-4R7S Patch power inductor 1 L1
2LG1-SWPA4020-2R2S Patch power inductor 4 L2, L3, L4, L6
2LW1-16UC-221J
Patch winding inductor
1
L5
2LW1-20UC-180J Patch winding inductor 2 L7, L33
2LW1-20UC-220J Patch winding inductor 2 L13, L32
98
