DR600 Service Manual
42 7SMF-030060M-SZCT-
N1
M3*6 cross recessed countersunk machine screw
, hardened
iron, black nickel plated
10
43 3CR7-N-60 RF coaxial line with N-shaped head, 60mm in length 1
44 6SS2-4224-BLA DR600-02 Ethernet adapter board suite 1
5.3 Wiring
37
