DR600 Service Manual
23 7MHL-4224-05A-W0 Laser carved logo on DR600 front panel, with copper cylinder 1
24 6SS2-4095-HRA STR-V receiving board suite, Sepura VHF repeater 1
25 4MF7-DFB402012H-1 Fan, 12V, with circular terminal 1
26 7MBF-4224-04A-Z Bottom panel of DR600 case, cold-rolled plate, zinc plated,
powder sprayed, welded
1
27 7MHL-4224-03A-W0
Right decoration strip of DR600 (included in DR600 case),
aluminum
1
28 7MHL-4027-03B-W Upper aluminum-alloy s
hield cover of DR550 receiving
module, die cast, machining renovated
1
29 7SMF-030180M-SZCT-
N1
M3*18 cross recessed countersunk machine screw, hardened
iron, countersunk thread, white nickel plated
16
30 7SMF-040080M-SZCT-
N1
M4*8 cross recessed countersunk machine screw (provided
by supplier), white nickel plated
4
31 6SS2-4224-HBA Nesting of baseband board, 400-470MHz 1
32 0ADY-4071-E Power module, MeanWell switching 12V power supply, 320W 1
33 6SS2-4071-HWB Nesting of STR-U power supply board 1
34 7MBF-4224-02A-Z Back panel of DR600 case, 2mm thick cold-rolled plate, with
GPS jack
1
35 7SAF-040100M-SZLJ-
Z1
M4*10 cross recessed outer hexagon
hardened iron, black plated
8
36 3CP3-YB-B2-Q1 YB-B2-Q power socket, with Littelfuse double fuses 1
37 7MHS-4224-03A-W0 Shield cover of power supply, 0.3mm stainless steel 1
38 7MHS-4027-06A-W M4*8 grounding bolt set, stainless steel 1
39 3WPC-WS20K2Z Two-core aerial socket with flange plate, with dust cover 1
40 3CR7-BNC-185 BNC RF coaxial line, RG141A/U, 175mm in length 1
41 6SS2-4071-HL1A STR-U nesting of attachment plate 1
36
