DR600 Service Manual
5 7SAF-030050M-SZYB-
Z1
M3*5 cross recessed round-and-mushroom headed machine
screw, hardened iron
23
6 7SAF-030080M-SZYB-
Z1
M3*8 cross recessed round-and-mushroom headed machine
screw
18
7 7MHZ-1731-01A-J5 3300 speaker insulation paper, highland barley paper,
18*8*0.2mm, with adhesive
1
8 6SS2-4095-HPA STR-V, power amplifier board suite, Sepura VHF repeater 1
9 7MMC-1943-01A-N
Shield cover of PT8200 power module, made of brass and
electroless nickel, lead-free
1
10 7MHL-4224-04A-W0 DR600 radiator, aluminum alloy, 1
11 7MHL-4224-02A-W0
Left decoration strip of DR600 (included in DR600 case),
aluminum
1
12 7SMF-030250M-SZCT-
N1
M3*25 cross recessed countersunk machine screw, hardened
iron, coarse thread, white nickel plated
20
13 7MHL-4027-05B-W Upper aluminum-alloy
shield cover of DR550 transmitting
module, die cast, glue dispensed
1
14 7MHS-4224-02A-W0 DR600 fan shroud, 0.3mm stainless steel 1
15 7SMF-030060M-SZYB
-N
M3*6 cross recessed round-and-mushroom headed machine
screw, hardened iron, nickel plated thread
60
16 6SS2-4095-HTA STR-V transmitting board suite, Sepura VHF repeater 1
17 7MHL-4027-04A-W Lower aluminum-alloy
shield cover of DR550 transmitting
module, die cast, machining renovated
1
18 7MHP-4224-01A-W0 Handle of 1U Case, with a screw 2
19 4MF7-DFB402012H-2 2 parallel fans, 12V, cable 370mm in length, with a connector 1
20 6SS2-4224-HFA Nesting of front panel of transceiver 1
21 3SB3-HS16A-P11Z Metal button switch 1
22 7MHL-4027-02A-W Lower aluminum-alloy shield cover o
module, die-cast mould, machining renovated,
1
35
