Kirisun DR600 Service Manual

DR600 Service Manual
Table 11 Parts List (Enternet Board)
Part No. Part Name Quantity Location
0SS2-4224-BLA Plug-in material for DR600-02 Ethernet
pinboard
1
3CT3-XW93796-8P Ethernet board 1 J1
3CB3-S6125BM1 Board-to-board connector 2 J12
3CB3-S6125BM2 Board-to-board connnector 2 J12
6SS1-4224-BLA
DR600-02 Ethernet pinboard
1
0SS1-4224-BLA SMT material of DR600-02 Ethernet
pinboard
1
2CC1-16-X7R500-104K
R multi-layer chip capacitor
1
C1
2CC1-16-X7R500-103K R multi-layer chip capacitor 1 C2
2CC1-16-X7R500-102K R multi-layer chip capacitor 1 C3
2CC1-32-C0G102-102J R multi-layer chip capacitor 2 C4,C5
1DS1-LT-B3D090L
Three-end gas discharge tube
2
D1,D2
2TI1-11FB-05NL Ethernet transformer 1 F1
1IM1-SLVU2.8-4 TVS chip 1 IC1
2RS1-16-750J Pellet resistance 2 R1,R2
2RS1-32-220J
Pellet resistance
4
R3,R4,R5,R6
2RS1-16-755J Pellet resistance 1 R8
6PD7-4224-HGA DR600-02 thunder-proof Ethernet interface
board
1
7PLZ-012006-P01A Barcode lable 1.05
104

Kirisun DR600 Specifications

General

Brand	Kirisun
Model	DR600
Category	Repeater
Language	English
