DR600 Service Manual
129
C207103
C201
C202103
C200103
Q200
DTC114YE
100uF/25v
C203
C206103
R203
8.2K
1 2
CB300 3A
C208103
MM3Z12VT1G
D200
1
ADJUST
2
ON/OFF
3
GND
4
IN
5
OUT
U200 LM2941S
GND
0
103
22uF/10v C205
R200 47K
L200
BLM21PG300S
47K
R201
NC
R202
C204103
VCC
8T
TXENABLE
