DR600 Service Manual
135
C285
103
1 2
CB1 3A
R11447K
R115
47K
C286
103
L68
BLM21PG300S
MM3Z12VT1G
D43
Q22
DTC114YE
100uF/25v
C287
R116
8.2K
C288
103
R117NC
C289
103
C290
103
103 C291
1
ADJUST
2
ON/OFF
3
GND
4
IN
5
OUT
GND
0
U4 LM2941S
22uF/25v
C292
C293
103
VCC
8R
VCC8RX
