DR600 Service Manual
Intermodulation
ETSI: 70dB TIA603: 75dB
Adjacent Channel
Selectivity
ETSI/TIA603: 60dB@12.5kHz, 70dB@20/25kHz
Spurious Response
Rejection
ETSI/TIA603: 70dB
Conducted Spurious
Emission
-57dBm
Impedance
ETSI: 84dB TIA603: 80dB
Rated Audio
Distortion
<3％
Hum and noise
-40dB@12.5kHz/-43dB@20kHz/-45dB@25kHz
Audio Response
+1dB ~ -3dB
Tx Parameter
Frequency Stability ±1.5ppm
Tx Power
Low: 25W, high: 40W
Hum and noise
-40dB@12.5kHz/-43dB@20kHz/-45dB@25kHz
Conducted Radiated
Emission
-36dBm@<1GHz, -30dBm@>1GHz
Adjacent Channel
Power
60dB@12.5kHz, 70dB@20/25kHz
FM Modulation
11K0F3E@12.5kHz, 14K0F3E@20kHz, 16K0F3E@25kHz
4FSK Modulation
12.5kHz(Only data): 7K60FXD
12.5kHz(data+speech): 7K60FXE
Modulation Limiting ±2.5kHz@12.5kHz, ±4kHz@20kHz, ±5kHz@25kHz
Audio Response
+1dB~-3dB
Audio Distortion 3％
45
