Kirisun DR600 Service Manual

DR600 Service Manual
3K
capacitor
2CC1-16-Y5V160-10
4Z
flake multi-layer
capacitor
1608, 100nF+80%/-20%, 16V, Y5V 19 C110, C112, C114, C158, C159, C162,
C185, C187, C195, C196, C209, C213,
C215, C217, C227, C229, C238, C241,
C243
2CE1-VS250-101M0
607D
SMD aluminum
electrolytic capacitor
SMD-6.3x7.7mm, 100uF/25V 1 C403
2CT1-TS32-160-4R7
M
R SMD tantalum
capacitor
3216, 4.7μF±20%, 16V, TS series (A level) 1 C178
2CT1-TS32-160-100
M
R SMD tantalum
capacitor
3216, 10μF±20%, 16V, TS series (A level) 21 C100, C104, C115, C120, C121, C126,
C252, C254, C282, C283, C284, C285,
C286, C287, C288, C293, C294, C299,
C328, C333, C405
2CT1-TS32-350-R10
M
R SMD tantalum
capacitor
3216, 0.1μF±20%, 35V, TS series (A level) 3 C172, C173, C174
2CC1-16-C0G500-24
0J
R flake multi-layer
capacitor
1608, 24P±5%, 50V, C0G 3 C176, C183, C132
2CT1-TS32-6R3-150
M
R SMD tantalum
capacitor
3216, 15μF±20%, 6.3V, TS series (A level)
1
C109
2LL1-16-3R3K R laminated inductor 1608, 3.3μH±10%(MLF1608A3R3K TA00) 2 L105, L117
2LW1-16UC-181J SMD wire winding
inductor
1608, 180nH±5%, ceramic core
(C1608CB-R18J)
1 L205
2LW1-16UC-560G SMD wire winding
inductor
1608, 56nH±2%, ceramic core
(C1608CB-56NG)
1 L113
2LW1-16UC-R33G SMD wire winding
inductor
1608, 330nH±2%(C1608BR33G), pb-free 6 L103, L104, L111, L115, L116, L120
2LW1-20UC-102J
SMD wire winding
inductor
2012, 1μH±5%, ceramic core
(C2012C-1R0J)
2
L214, L106
2LW1-20UC-470GB SMD wire winding
inductor
2012, 47nH±2%, 500mA,
LQW2BAS47NG00, SMD wire winding
inductor, muRata brand
1 L119
82
