TM840 Service Manual
28 1DZ1-LM3Z18VT1G Chip Zener diode 1 D16
29 1DZ1-BZB784-C3V3 Zener diode 1 D3
30 1TF1-2N7002 Chip MOSFET 1 Q11
31 1DG1-CM1293A Chip MOSFET 3 U13，U14，U15
32 6BLS-4814-03327U
Chip button battery (DP770，DM890，PT7800，
219，620D)
1 BT1
33 3CF1-40FMN-SMT-A-TF R Chip FFC/FPC connector 1 J5
34 3CC1-USB-UH51543-CS7 USB port AB type socket 1 J24
35 3CR1-MM9329-2700 RF coaxial connector 1 C91
36 1TT1-DTA144EE R Chip triode 1 Q56
37 1TT1-2SC4617-R R Chip triode 6 Q1005，Q13，Q54，Q25，Q52，Q57
38 1TT1-DTC144EE R Chip triode 25
Q3，Q4，Q6，Q7，Q8，Q9，Q20，Q21，Q23，Q32，Q33，Q34，Q35，Q36，Q37，Q38，Q39，Q40，Q41，Q42，Q43，Q44，Q45，Q59，Q4001，
Q60
39 1TT1-DTC114YE Chip triode 5 Q31，Q46，53，Q104，Q5
40 1TF1-PHD27NQ10T Chip MOSFET 1 Q1
41 1TT1-FMMT717TA R Chip triode 3 Q47，Q50，Q103
42 1TF1-ST2301 R Chip MOSFET 4 Q2，Q10，Q61，Q58
43 1TT1-2SC3356-R24 R Chip triode 9 Q26，Q27，Q4000，Q28，Q29，Q24，Q18，Q19，Q55
44 1IS1-XC6209F502PR Chip voltage stabilization IC 6 Q12，Q16，Q17，Q22，Q30，Q51
45 1IS1-XC6209B552MR Chip voltage stabilization IC 1 Q14
46 1IS1-XC6209F332PR Chip voltage stabilization IC 2 Q4002，Q15
47 1IS1-XC6228D122VR Chip special IC SPURAL FP520 FM540 1 U12
48 1IS1-LM2941S Chip special IC 1 U16
49 1IS1-PGA103 Broad Band low noise amplifier 2 U31，U36
50 1IS1-GVA63 High-gain Amplifier High-gain Amplifier 2 U42，U46
51 1IS1-GVA84 High-gain Amplifier High-gain Amplifier 1 U51
52 1IS1-TPS65023
power supply management IC DP770，DP780，
KH620D，STR，STP
1 U3
53 1IS1-RT9193-33PB Chip voltage stabilization IC 1 U10
54 3CP1-TPS76301 LDO power supply voltage stabilizer 1 U112
55 1IS1-TPS2051BDGN IC LDO power supply voltage stabilizer IC 1 U7
56 1IS1-LT4356-1 IC Overvoltage Protection IC 1 U2
57 1IS1-AD9864 Digital System 1 U4000
58 1IS1-ADS1015 AD convertor IC 2 U11，U22
59 1IS1-MAX98400B D type high power amplifier 1 U18
60 1IS1-MC74VHC1GT66 IC High speed CMOS analog switch IC 2 U30，U110
61 1IM1-MT47H64M16 Chip storage IC 1 U5
62 1IP1-OMAPL138BZWT3 Dicaryon CPU 1 U4
63 1IS1-PCF8563TS Chip Special IC 1 U20
