TM840 Service Manual
Appendix Spare Part List and Schematic Diagram
Table1400-470MHz Parts List（Electrics Section）
NO.
Material No. Description Quantity Position No.
1 5XC1-32R8-FC-135 Chip Crystal Resonator STP-U，DP770V 2 Y1，Y3
2 5XC1-19R2-TKL3056B Chip crystal oscillator DP770 STP KH620 1 Y2
3 5OT1-12R8-CEC3-0503 R Chip TCXO 1 X500
4 5XC1-18R4-CEC5032SCH Chip crystal oscillator STM，DP780 1 X801
5 5XC1-73R4-D73312GQ12 Chip crystal oscillator STP，STM，KH620D 2 Z1，Z202
6 5FQ1-LFCN-490 Low Pass filter 2 U43，U47
7 5FE1-BLM11A601S R Chip EMI suppression filter 17 FB23，FB24，FB26，FB27，FB30，FB203，R6038，R6045，R6046，R6047，R6048，R6049，R6050，R6051，L11 ，L1003，L1004
8 5FE1-BLM18PG181SN1 Chip EMI suppression filter 14 FB25，FB3，FB4，FB5，FB6，FB7，FB8，FB41，FB43，FB44，FB13，FB14，FB31，FB32
9 5FE1-BLM41P600SPT R Chip EMI suppression filter 3 FB28，L6，L13
10 5FE1-BLM21PG221SN1 Chip EMI suppression filter 6 FB73，FB12，FB21，FB22，FB59，FB60
11 5FE1-BLM15AG221SN1D EMI suppression filter 39
R818，FB64，FB65，FB66，FB67，FB68，FB70，FB71，FB69，FB9，FB61，FB62，FB38，FB39，FB40，FB42，FB45，FB46，FB47，FB48，FB49，
FB50，FB51，FB52，FB53，FB10，FB11，FB55，FB56，FB63，FB36，FB54，FB37，FB72，FB807，FB1，FB2，FB57，FB58
12 3FW1-42932-302320 R Chip fuse 1 FB19
13 1DS1-DA2S10100L R Chip switching diode 9 D4，D6，D7，D37，D1001，D12，D44，D45，D11
14 1DS1-HVC131 R Chip switching diode 6 D10，D18，D41，D40，D42，D43
15 1DS1-L8104 Chip switching diode (1DS1-L709CE） 3 D27，D29，D39
16 1DS1-RB706F-40 R Chip switching diode 3 D31，D103，D38
17 1DV1-HVC350B R Chip variode 9 D19，D28，D24，D33，D13，D14，D15，D3015，D3017
18 1DV1-1SV305 R Chip variode 18 D117，D116，D4000，D125，D126，D121，D122，D113，D105，D107，D108，D109，D26，D111，D101，D102，D25，D106
19 1DV1-HVC376B R Chip variode 1 D4001
20 1DG1-DSM3MA1 R Chip general-purpose diode 1 D8
21 1DR1-SS36 Chip rectifier diode 1 D1
22 1DZ1-HZU5CLL R Chip Zener diode 1 D35
23 1DZ1-PESD24V0S1UB Chip Zener diode 1 D17
24 1DZ1-PESD3V3S1UB Chip Zener diode 6 D61，D57，D62，D58，D59，D60，
25 1DZ1-PESD5V0S1UB Chip Zener diode DP770，DP780，STP，KH620 14 D55，D51，D50，D49，D20，D21，D22，D46，D47，D48，D52，D53，D54，D56
26 1DR1-SMCJ20A Chip diode 1 D2
27 4PE1-16-F2-G R Chip luminous diode 1 LED2
