Kirisun TM840 Service Manual

TM840 Service Manual
267 2RS1-10-392J R chip capacitor 1 R388
268 2RS1-10-222J R chip capacitor 1 R177
269 2RS1-10-683J R chip capacitor 1 R140
270 2CC1-32-Y5V500-106Z chip multilayer capacitor 2 C106，C135
271 1DR1-TPD4S012DRY TVS triode 1 U19
272 7PLJ-025006-T01A
High-
temperature sticker SEPURA DMR
barcode sticker
1.05
273 2CC1-16-C0G500-130J R chip multilayer capacitor 2 C3006,C255
274 1IP1-000SxM-R01 SxM8010 programming chip 1
275 1IM1-NANDS34ML01G1 SMD memorizer IC,only for SEPURA 1 U6
276 9FSO-SxMV000 SxM8010 programming software 1
Table3 Parts List（Structure Section）
No Material No Description Quantity Remark
1 7MBP-4062-01B-W0 DM850 Front Cover 1
2 7MBP-4062-05A-W0 DM850 Button Stent 1
3 7MBR-4062-01A-W DM850 Function Button 1
4 7MBR-4062-02A-W3 DM850 Emergency Button 1
5 7GCM-4062-01A-W DM850_LCD dust-proof mat 1
6 7MBB-7220-01A-W0 PT8200M Speaker dust-proof 1
7 7GGP-S1943-J PT8200 Speaker washer 1
8 3WPT-S1938-01A Black and white twisted pair 1
9 4SS7-3520-016-700 Speaker 1
10 7MBP-4062-01B-W0 DM850 lens double faced adhesive tape 1
11 7MBP-4073-02A-W0A STM-U rear cover(spray lacquer) 1
12 7MBP-4073-03A-W0 STM-U Plastic upper cover 1
13 7MBP-4073-04A-W0 STM-U volume knob 1
14 7MBR-4062-03A-W0 DM850 Handpiece waterproof Ring 1
15 7MBR-4062-04A-W0 DM850 complete machine waterproof ring 1
16 7MBR-4062-05A-W0 DM850 mainframe waterproof Ring 1
17 7MBR-4062-06A-W0 DM850 aluminum alloy below cover waterproof Ring 1
18 7MBR-4062-07A-W0 DM850 Switch waterproof pad 1
19 7MBR-4062-08A-W0 DM850 Power Socket Water- proof pad 1
20 7MBR-4062-09A-W0 DM850 Antenna Connector water-proof ring 1
21 7MBR-4062-10A-W0 DM850_DB26P waterproof rubber cover 1
22 7MBR-4062-11A-W0 DM850_GPS Antenna head waterproof Ring 1
55

Kirisun TM840 Specifications

General

Brand	Kirisun
Model	TM840
Category	Radio
Language	English
